Vguard Borewell submersible pump 1.5 hp upto 360 feet with digital control panel

4.7 / 5.0 • 28 ratings • Model: th559
SAVE ₹2,500 (13% OFF)
Vguard Borewell submersible pump 1.5 hp upto 360 feet with digital control panel
Vguard Borewell submersible pump 1.5 hp upto 360 feet with digital control panel
100% Genuine
Authorized Dealer
APS Courier Hub
2–3 Days Delivery
Tech Support
Installation Advice
Visit the Vguard Store
• Model: th559 • In Stock

Vguard Borewell submersible pump 1.5 hp upto 360 feet with digital control panel

4.7 / 5.0 • 28 ratings • Model: th559 • Borewell submersible pump
₹17,000 ₹19,500 Save ₹2,500 (13% OFF)
Inclusive of all taxes • GST commercial invoice provided
Delivery across Kerala • APS Hub or Home Delivery View Delivery Options ↓
Card Offers 8 Offers Active
₹50 Gift Card • Up to 10% Rewards
Amazon Pay ICICI, Scapia, PhonePe SBI • 8 Offers
ICICI
Scapia
SBI
Axis
View Offers ›
UPI Offers Instant Cashback
Up to ₹200 Cashback • 5% NeuCoins
Tata Neu, Paytm, Navi, BHIM, super.money • 7 Offers
Tata Neu
Paytm
Navi
BHIM
View Offers ›
Save more with payment offers on checkout
Offers auto-apply in Razorpay window on entering card or UPI details
Power
phase motor for lifting water from deep borewells.
Electricity
Single Phase
Total Head
Up to 110 Mtr (360 Feet)
Discharge
90 Litres/Min (1.5 L/Sec)
Speed
2800 RPM
Protection
IP68 Submersible
Quantity:
−
+
In Stock • Fast Dispatch via APS Hub
Order on WhatsApp
Need Expert Guidance?
(+91) 85930 62005 (+91) 90481 68319
Check APS Courier Delivery Timeline In Stock
Quick PIN:
GST Commercial Invoice
Eligible for input tax credit
Installation Guidance
Free head & pipe advice
Product Overview
1.5hp Vguard Borewell Submersible pumpset upto 360 feet. Oil cooled.1800 lph @110 meters Including panel board

 Oil-Cooled Motor: Essential for deep bore (~135 m head) — many standard “15 stage” cheap pumps are water-filled or not rated for such head unless specified.
 Performance Curve: Make sure the specific model states ~1800 LPH at ~110 m head (or closely similar). Performance varies by stage count & motor design.
 Control Panel: Some listings include the panel board; some require separate purchase — always verify in the seller spec.

1. Powerful 1.5 HP Oil-Filled Motor

  • Robust 1.5 HP single-phase motor for lifting water from deep borewells.

  • Oil-cooled design helps dissipate heat more efficiently than water-filled motors, which reduces thermal stress during continuous operation and improves durability.

2. Multistage Pump Construction

  • Multiple impeller stages build up pressure to lift water from great depths — more stages = higher head.

  • Stainless steel or corrosion-resistant impellers & casing materials help resist wear from abrasive water conditions.

3. Stainless Steel and Corrosion-Resistant Build

  • Stainless steel motor shaft and hardware protect against rust and mineral corrosion inside the borewell.

  • Rigid cast iron housing parts on some models add mechanical strength.

  • Non-return valve internal design prevents back-flow and helps maintain prime.

4. Wide Voltage Operating Range

  • Designed to work reliably under voltage fluctuations common in many residential and rural electrical supplies (typically ~180-240 V).

  • This helps avoid motor stress and improves long-term reliability.

5. Automatic Start / Stop Control

  • The panel automatically starts and stops the pump based on water availability or demand.

  • This reduces manual intervention and avoids dry-running damage.

  • Some panels may include contactor/relay-based protection for safer motor control.

6. Overload & Electrical Protection

  • Built-in overload protection helps guard the motor against excessive current draw that can happen on deep, heavy loading.

  • Some panels also include voltage spike and drop protection to shield electronics and motors.

7. Dry-Run Protection (in higher-end panels)

  • Detects when there’s insufficient water in the bore and shuts off the pump automatically to prevent dry running — a common cause of motor burnouts. (Note: this is typical on many “smart” pump controller panels, though specific panel models vary.)

8. Digital Status / Indicators

  • Digital panels may include LED/Display indicators for status, faults, and operational conditions, helping you quickly identify issues without testing manually.

  • Some advanced pump panels can even show real-time operating parameters (depends on panel )

  • Vguard 1.5HP borewell submersible pump is designed for efficient water pumping up to 300 feet .This single phase submersible water is ideal for domestic and agricultural applications with reliable water flow and energy efficient performance.Supplied with a digital control panel,it provides advanced motor protection and long lasting operation
Key Specifications Summary
Power phase motor for lifting water from deep borewells.
Electricity Single Phase
Total Head Up to 110 Mtr (360 Feet)
Discharge 90 Litres/Min (1.5 L/Sec)
Speed 2800 RPM
What's In The Box & Delivery Logistics

• 1 x Vguard Borewell submersible pump 1.5 hp upto 360 feet with digital control panel

• 1 x Technical Installation Guide & Manual

• 1 x Manufacturer Warranty Card & GST Bill

Delivery & Dispatch Details:

• Parcel Charge: Extra ₹300/- for all products.

• Courier Partner Hub: Dispatched safely to your nearest APS (Alleppey Parcel Service) hub across Kerala & South India.

• Consignment Receipt: Lorry Receipt (LR) tracking copy sent via WhatsApp once booked.

• Home Delivery: Direct doorstep transport available upon request.

Warranty & Showroom Service
Official manufacturer warranty backed by Tharakan Machines. On-site assistance, warranty registration, and spare parts available at our Post Office Road, Thrissur showroom.
Tharakan Machines Showroom
Post Office Road (opp. Double X Hotel), Thrissur
View Map →
Technical Specifications
Features & Benefits
Delivery & Dispatch Options

Complete Technical Specifications (Model: th559) — Verified from manufacturer nameplate

Robust 1.5 HP singlephase motor for lifting water from deep borewells.
Oilcooled design helps dissipate heat more efficiently than water-filled motors, which reduces thermal stress during continuous operation and improves durability.
Stainless steel or corrosionresistant impellers & casing materials help resist wear from abrasive water conditions.
Nonreturn valve internal design prevents back-flow and helps maintain prime.
Builtin overload protection helps guard the motor against excessive current draw that can happen on deep, heavy loading.

Similar Pumps & Recommendations

Other popular water pumps available at our Thrissur showroom

View All →
Got Questions?

Frequently Asked Questions (FAQs)

Everything you need to know about the Vguard Borewell submersible pump 1.5 hp upto 360 feet with digital control panel, delivery across Kerala, and warranty.

1 What power supply and electrical requirements apply to this single-phase pump?
2 What is the maximum head capacity and water discharge flow rate?
3 How does delivery to the nearest APS (Alleppey Parcel Service) hub work?
4 Can I get direct doorstep or farm delivery instead of collecting from the APS hub?
5 Does Vguard provide official warranty and GST invoice with this purchase?
6 What is the build quality, duty cycle, and protection rating of this pump?
